| 圖 片 | 編 號(hào) | 位 置 | 品名尺寸 | 適用機(jī)種 | 原廠編號(hào) |
|---|---|---|---|---|---|
 |
M117 | Upper & Lower |
鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-H1,HA,SA,SB | X054D171G54 |
 |
M107 | Upper | 鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-J.JA.SA.SB.SZ | X052B054G53 X052B054G54 X052B054G55 |
 |
M103 | Upper & Lower |
鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-F,F1,G,H,H',H1,HA,C | X052B040G64 X052B040G65 X052B040G66 |
 |
M140 | Upper | 陶瓷穿線眼模 Ceramic Guide D 12*0.35*33.4L |
DWC-FA-S | X056C082H01 |
 |
M123 | Upper & Lower |
鑽石眼模裝卸工具 Wire Guider Opener For M132.M133 |
DWC-HA,SZ,SX,FX,RA,FA AF2,AF3,AT |
|
 |
M135 | Upper | 鑽石螺絲 Sub Die Guide A |
DWC-XC,FX,FA,RA,QA AF2,AF3 |
X054D896G51 |
 |
M120 | DWC-H1,HA,SA,SB,AF1 | 鑽石螺絲 Set Screw |
X053C628G51 | X053C628G51 |
 |
M113 | Upper & Lower |
鑽石螺絲 Set Screw 0.4mm L:12.5mm |
DWC-H1,HA,SA,SB | X054D162G54 |
 |
M108 | Upper & Lower |
鑽石螺絲 Set Screw 0.4mm L:11mm |
DWC-N,F,F1,G | X052B123G53 X052B123G54 X052B123G56 |
 |
M009-1 | Upper | 給電板連動(dòng)把手 Power Feed Contact Opener For M009 |
DWC-FA,FA10S,FA20S, DWC-FA30S,FA-V575 |
X059D448G52/2210000716 |
